Product Features

Professional and systematic cycles configuration with sterlization cycles such as fabric, instrument- rubber, quick, iquid, umen; and BD,PCD, leak test and othe auxiliary cycles.

LCD display of temperature, pressure, time, operation status and fault alarm.

Inteligent dying system, residual humidity does not exceed 0.2% ater instrument drying, and residual humidity does not exceed 1% after beddings drying.

Built-in steam generator, microcomputer temperature control technology, saving time and energy.

Equipped with printer to print date, time and process parameters.

Automatic over-temperatur protection device, two-way safety interlock device for door pressure and temperature, safety valve for over-pressure automatic pressure relief, short-circuit protection, over-voltage protection.

Perfect four levels of authority management svstem, effective prevention of mis-operation.

Design pressure: -0.1/0.25MPa (plateau area: -0.1/0.28MPa)

Sterilization working temperature: 115~138°C

Accuracy of pressure display: 1Kpa

Vacuum lower limit: -0.080Mpa

Temperature display accuracy: 0.1°C

Note: If there are strong corrosive substances in laboratoy for users, please choose M1 configuration (full 316L cabinet),Order No. (M1); lf for plateau area,please add-G in the regular Order No..
